mosaic-G5 P1
Ultra-compact high-precision GPS/GNSS receiver module with essential functionality
- Ultra small in size, essential functionality
- Triple band satellite tracking: multi-constellation, multi-frequency GNSS / GPS receiver
- Excellent RTK positioning accuracy
- Industry-leading ultra-low power consumption
- Easy-to-integrate, optimized for automated assembly
- Advanced GNSS+ algorithms
Note: this product will be commercially available from Fall 2025 onwards - please contact us for urgent requests.
Ideal for size-constrained applications
Septentrio mosaic-G5 P1™ is a very small size multi-frequency GNSS receiver module in a low-power surface mount package. It tracks all GNSS constellations and delivers reliable high-accuracy positioning even in challenging environments. With a comprehensive set of interfaces, this receiver has been designed for the growing market of high-precision applications like UAV and autonomous systems. It has low and predictable latency needed for stable and accurate control systems. It is also easy to integrate and is compatible with popular open-source autopilots.
Top value for mass market applications
Sized at only 22.8 x 16.4 mm, mosaic-G5 P1™ offers unmatched size to performance ratio. It delivers centimeter-level positioning and fits into space-constrained applications such as drones, robots, handheld devices or wearables.
Designed for automated assembly
The mosaic-G5 P1™ GNSS module is designed for high volume automated assembly lines.
Ultra-low power design
The mosaic-G5 P1™ provides RTK positioning at a very low power consumption.
Easy-to-integrate with intuitive set-up and control software: RxTools
This GNSS receiver includes an intuitive user interface for easy operation and monitoring allowing you to control the receiver and analyze its data. This interface also offers easy-to-read quality indicators ideal for monitor the GNSS receiver operation during the job at hand. All interfaces, commands and data messages are fully documented. The RxTools software suite allows convenient receiver configuration and analysis.
Evaluating the GPS / GNSS receiver
The mosaic-go G5 evaluation kit can be used for easy testing and prototyping of mosaic-G5 P3 and mosaic-G5 P3H receivers.
GNSS+ Technologies - Top performance in challenging environments:
Septentrio has been perfecting its GNSS+ algorithms for the past 25 years. Get the most out of your GNSS receiver even in challenging environments. Protect your GNSS receiver from:
Mechanical vibrations or shocks caused by rough terrain can wreak havoc with satellite tracking. LOCK+ automatically adjusts the parameters of this receiver so you never lose position.
Metal and large nearby structures can reflect GNSS signals and produce multipath. The APME+ system effectively disentangles direct and reflected GNSS signals enhancing both position and measurement quality. APME+ is bias free and, in line with Septentrio’s commitment to maximum configurability, can be disabled.
RAIM+ or Advanced Receiver Autonomous Integrity Monitoring comprises fault detection mechanisms of the receiver at all the levels including the generation of measurements, quality control and navigation algorithms. Detected faulty measurements, which are typically caused by high multipath or active ionosphere, are removed from the solution.
Activity in the ionosphere is a problem for GNSS signals, from loss of RTK fix to total loss of signal lock. Having honed our skills, supporting applications in the most iono-active areas on Earth, the result is IONO+: the most advanced protection against ionospheric disturbances to GNSS signals on any receiver.
The mosaic-G5 P1 offers AIM+ Basic functionality with GNSS & GPS jamming and spoofing detection as well as manual GNSS & GPS interference mitigation.
GNSS technology
| 789 | |
GPS: L1C/A, L1PY, L2C, L2P(Y), L5
|
|
GLONASS: L1CA, L2CA, L2P, L3 CDMA
|
|
BeiDou: B1I, B1C, B2a, B2I, B3I
|
|
Galileo: E1, E5a, E5b
|
|
QZSS: L1C/A, L1C/B, L2C, L5
|
|
NavIC: L5
|
|
L-band
|
|
5 constellation RTK (base and rover)
|
Septentrio patented GNSS+ technologies
Interfaces
USB device (2.0, HS)
|
1 |
| 2 | |
Initialisation time
|
7 s |
Other positioning modes accuracy
| 1.2 m | |
Vertical standalone
|
1.9 m |
Horizontal SBAS
|
0.6 m |
Vertical SBAS
|
0.8 m |
Horizontal DGNSS
|
0.4 m |
Vertical DGNSS
|
0.7 m |
